Comments for Page: Engine, Muffler & Clutch (Multi-Page)
1. Supplied with the engine.
2. Torque to 61–65 N•m. Replace (do not reuse) the cap screw if it is removed or loosened. Use only hand tools to install this fastener.
3. Torque to 41 N•m. Replace (do not reuse) the cap screw if it is removed or loosened. Use only hand tools to install this fastener.
4. Torque to 23 N•m.
FUEL & VAPOR LINE LENGTHS
A: 32 cm FUEL FILTER TO TANK (FUEL)
B: 86 cm ENGINE PURGE PORT TO VACUUM BREAKER (VAPOR)
Élément Numéro de pièce Qté Nom
28 601503 2 CB .250-20 X .625 ZN
29 606445 1 STARTER SOLENOID
30 768515 3 FW 0.281SAE
31 024927 3 NT .250-20HXG5
32 041152 2 NT 0.312-24 HX G8
33 602099 1 BATTERY CABLE, POS.
34 771428 1 BATTERY CBL BOOT-RED(FS)
35 601062 1 BATTERY CABLE, POS.
36 601841 1 BATTERY CABLE, NEG.
37 029876 1 LW .312 INTEXT ZN
Engine, Muffler & Clutch (Multi-Page)
48" TrimStar Parts Manual - 939504CE - HTTSRS048KAWFS600VC
Thu May 28 06:43:28 UTC 2020 6-1
