FasTraks with Kohler Engines
FOR ENGINES WITH SERIAL NUMBERS PRIOR TO 07102604 (FIG. 29):
FOR ENGINES WITH SERIAL NUMBERS 07102604 AND HIGHER:
Front of wire harness (FIG. 30). Route the 4" positive battery cable and the purple and red wires through the cable
boot prior to fastening hardware to solenoid (FIG. 31).
Route negative battery cable and wireharness (from seat and safety switches) through hole in the right side of frame
(FIG. 32).
FIG. 29
FIG. 30 FIG. 31
FIG. 32
POS. BAT.
CABLE
PUR/RED
WIRES
BOOT
WIREHARNESS
NEG. BATTERY CABLE
RIGHT SIDE
