HUSTLER X-ONE i User Manual

604466 4-11 REV D
Maintenance Locator Chart
1. Engine Oil Fill & Dipstick
2. Fuel Filte
r
3. E
ngine Air Cleaner
4. E
ngine Oil Drain Plug
5. B
attery
6. Fuel T
anks
7. Hydr
aulic Oil Reservoir
8. Hydr
aulic Oil Filter
9. Fron
t Wheel Bearing Zerks (2)
10. E
ngine Oil Filter
11. Deck Height Pivo
t Zerks (4)
12. Pa
rk Brake Switch
13. Drive T
ires
14. P
ump Idler Zerk (1)
15. Pu
mp Belt
16. Dec
k Pusher Arm Zerks (2)
17. Deck Belt
18. B
lades
19. Fuel Evapo
ration System Filter
20. Carbon
Canister
Figure 4-15
Figure 4-16 Figure 4-17 Figure 4-18
1
3
4
5
6
6
7
11
10
9
12
9
11
12
2
11
11
13
13
7
14
15
8
8
19
20
19
Carbon canister equipped mower
