at the time of image capture
The intended part may be
outside the range for image
captures.
Insert a compensation lens.
The quality of the captured
image is low.
The objective lens may be
contaminated.
Perform the cleaning.
The patient’s eyelid or
eyelashes may be interfering
with image capture.
Ask the patient to open their
eyes wider. If the patient
cannot open their eyes wider,
lift the patient’s lid, paying
attention not to press against
eyeballs.
The captured image is dark.
Alignment to and focus on
the anterior eye front may not
proper.
Manipulate the joystick to
align the working dot to the
center of the target mark.
The amount of light for image
capture may not be sufficient.
Increase flash intensity.
The internal fixation target is
blurred.
The internal fixation target
may be blurred because of
compensation lens.
Remove compensation lens.
Replacement
1. Replacing chinrest paper
① Pull out two fixing pins from chinrest.
② Put a new chinrest paper on the chinrest.
③ Insert two fixing pins into the chinrest paper hole.
④ Attach the chinrest paper to the chinrest.
