[ Replacement Chinrest paper ]
Please use the chinrest paper that provided by Huvitz Co.,Ltd.
2. Replacing fuse
① Ensure the power switch of device off (O).
② Remove power cable from inlet.
③ Pull out fuse holder in the inlet with a tweezers.
④ Replace two new fuses in the fuse holder. Be sure to check the fuse specification for the
replacement (250V T 3.15AL).
⑤ Insert fuse holder into the inlet.
Cleaning
1. Cleaning objective lens and anterior segment adopter
① Cover the objective lens with lens cap to protect the lens from external pollution.
② Use blower for removing dust on the surface of lens.
③ Any contaminants on the objective lens will affect the measurement.
Objective lens cap
Blower
