HWH SPACEMAKER - Room 1 Level In;Out Detailed Diagram

MP64.8279
22MAR10
E F
FLOOR LIFT CYLINDER
BREATHER/
FILLER
CAP
CYLINDER EXTEND
ROOM RETRACT VALVE
(1E)
CYLINDER RETRACT
ROOM EXTEND VALVE
(1R)
E & F - HOSES ARE 1/8" HIGH PRESSURE
HOSE SUPPLIED WITH THE MECHANISMS
G - HOSES MUST BE 1/8" HIGH PRESSURE
HOSE AND THEY MUST BE EQUAL LENGTH
H - HOSE MUST BE EQUAL LENGTH AND
THE SAME TYPE OF HOSES
ROD END
ROD END
CAP END END
FOR CONNECTION CLARITY,
ONLY THE ROOM CYLINDERS ARE SHOWN
E F
SYNC CYLINDER
ROOM CYLINDERS
CAP END
CONNECTION - C
ROD END
CONNECTION - A
ROOM CYLINDERS
CYLINDER EXTEND - ROOM RETRACT
CYLINDER RETRACT - ROOM EXTEND
CHECK OIL LEVEL WITH ROOM EXTENDED
CONNECTION
CAP END
ROD END
CONNECTION
FRONT VIEW
OF MECHANISM
CAP END
CONNECTION
AP24818
CAP
AP24632
CONNECTION
ROD END
G H G H1/4" HOSE HOSE
1/8" HP
HOSE
1/8" HP
HOSE
1/4"
PROPER HOSE CONNECTIONS ARE
CRITICAL PAY CLOSE ATTENTION TO
FITTING ORIENTATION ON FLOOR LIFT
1/4"
HOSE
HOSE
1/4"
1/4"
HOSE
HOSE
1/4"
CYLINDER AND SYNC CYLINDER
HYDRAULIC LINE CONNECTION DIAGRAM
UNIVERSAL LEVEL IN / LEVEL OUT ROOM EXTENSION
ROOM 1 - DRIVERS SIDE FRONT
PAGE 2 OF 3
A
D
C
B
B
C
A
