HWH SPACEMAKER - Rooms 2 & 3 Straight Out Detailed Diagram

MP64.8280
22MAR10
E F
CYLINDER EXTEND
ROOM RETRACT VALVE
(3E)
BREATHER/
FILLER
CAP
CYLINDER RETRACT
ROOM EXTEND VALVE
(3R)
ROD ENDROD END
CAP END END
FOR CONNECTION CLARITY,
ONLY THE ROOM CYLINDERS ARE SHOWN
E F
SYNC CYLINDER
ROOM CYLINDERS
CAP END
CONNECTION - A
ROD END
CONNECTION - B
ROOM CYLINDERS
CYLINDER EXTEND - ROOM RETRACT
CYLINDER RETRACT - ROOM EXTEND
CHECK OIL LEVEL WITH ROOM EXTENDED
CONNECTION
CAP END
ROD END
CONNECTION
FRONT VIEW
OF MECHANISM
CAP END
CONNECTION
AP24818
CAP
AP24632
CONNECTION
ROD END
G H G HHOSE
1/8" HP
HOSE
1/8" HP
1/4"
HOSE
THE SAME TYPE OF HOSES
H - HOSE MUST BE EQUAL LENGTH AND
HOSE AND THEY MUST BE EQUAL LENGTH
G - HOSES MUST BE 1/8" HIGH PRESSURE
HOSE SUPPLIED WITH THE MECHANISMS
E & F - HOSES ARE 1/8" HIGH PRESSURE
CYLINDER RETRACT
ROOM EXTEND VALVE
(2R)
ROOM 2 CONNECTIONS
(SAME AS ROOM 3)
HOSE
1/4"
1/4"
HOSE
1/4" HOSE
CYLINDER EXTEND
ROOM RETRACT VALVE
(2E)
PAGE 3 OF 3
ROOM 2 DRIVER SIDE REAR & 3 PASSENGER SIDE REAR
UNIVERSAL STRAIGHT OUT ROOM EXTENSION
HYDRAULIC LINE CONNECTION DIAGRAM
