CONNECTING THE INPUTS
CONNECTING THE OUTPUTS
Use the XLR input (female) connectors (7) on the rear panel to supply audio signals to your
Hybrid DSP24 from your mixer or pre-amplifier. Balanced (recommended) or unbalanced connections
may be used with pin 2 configured as the non-inverting (+) pin.
Use the XLR output (male) connectors (8) on the rear panel to supply audio signals to your bass
amplifier. When using presets 1 to 30, the output connectors (8) marked as BASS 1 and 2 are locked as
bass outputs and must be connected to the bass amplifier. Balanced and unbalanced connections may
be used with pin 2 configured as the non-inverting (+) pin. Use the XLR output (male) connectors (9) on
the rear panel to supply audio signals to your second amplifier. When using presets 1 to 30, the output
connectors (9) marked as MID-HI 3 and 4 are locked as mid–high outputs and must be connected to
the mid–high amplifier. Balanced (recommended) and unbalanced connections may be used with pin 2
configured as the non-inverting (+) pin.
OPEN PRESETS 31 and 32 (CATEGORY 2)
SETUP
Now that you have installed your Hybrid DSP24, correctly connected both inputs to a mixer or
pre-amplifier and connected the four outputs to the correct amplifiers, you are ready to set up your
system for optimal performance and protection.
The Hybrid DSP24 has 32 presets that are divided into three categories. Depending on the speakers
and amplifiers used, your technical ability and your experience with processors, you can decide which
preset category to use. The following sections will guide you in making your decision.
SEMI-OPEN USER PRESETS 01, 02 and 03 (CATEGORY
These presets should be used when brands other than Hybrid are used AND the user/installer is NOT
familiar with or experienced in setting up systems that use digital processors. Follow the step-by-step
guide below for a well-balanced and protected system. Presets 01 to 03 can be partially edited by the
user, but many critical parameters have already been set.
8 × PEQs for linked outputs 1 and 2 as well as
outputs 3 and 4, each with selectable filters
(high-shelf, low-shelf, notch, high-pass and
low-pass)
Time-alignment up to 15 ms on linked outputs
1 and 2 and linked outputs 3 and 4
Linked outputs 1 and 2 as well as linked
outputs 3 and 4 have a limiter with attack,
release and threshold
Independent phase invert for all outputs
Independent mute function for all outputs
Electronic Earth-lift
Utilities menu allows you to load the preset
from a smart device, save the preset to a smart
device, write the preset to the DSP24, change
and save the password, upgrade the firmware
and change the LED logo’s colour and intensity
Presets 31 and 32 are completely open; thus, all functions and features can be edited using a PC/
smart device. These presets are for professional use and should only be used when the user/installer
is familiar with and/or experienced in setting up systems that use a digital processor. The controls and
features for presets 30 and 31 are listed below.
Linked left and right inputs
4 x input PEQs, each with selectable filters
(high-shelf, low-shelf, notch, high-pass
and low-pass)
Outputs 1 and 2 as well as outputs 3 and 4 linked
by default
HPF or LPF with 6, 12, 18 and 24 dB/oct slopes
Crossover types include Linkwitz-Riley,
Butterworth or Bessel filters
Linked outputs 1 and 2 as well as Linked outputs
3 and 4 can switch between PEQ and 30-band
graphic EQ
