User Manual | Temperature Controller Display HIB123 Part-No.: 3756766 Doc.-Version: I
KK 3 | nominal value, flow temperature
Adjustable: For fixed-value closed-loop control
Display only: for closed-loop control with ambient temperature reference
Notice: corresponds to the value when the SET button is pressed
in the home screen (for measured value LED °C3)
KK 3 | Set point offset to ambient temperature
Use at ambient-temperature control
KK 3 | Lower limit for warning U30
relative value to set point parameter S3
KK 3 | Upper limit for warning U31
relative value to set point parameter S3
Lower limit for flow alarm E01
Flow warning U04
offset to A20
Software-Version (f.e. V1.04.0)
Notes:
is shown only, when an ambient temperature sensor is activated internally.
is shown only, when the current control mode „fixed value“.
is shown only, when the current control mode „ambient value“.
is shown only when a conductance control is possible.
is shown only when a flow sensor with analogue output is available.
is shown only when a flow warning is supported by the controller.
is shown only when the view is supported by the controller.
For 2-circuit/3-circuit closed-loop control:
only displayed if an ambient sensor was also internally activated.
only displayed if the current control mode for KK 2 is “fixed value”.
only displayed if the current control mode for KK 2 is “ambient reference”.
only displayed if KK 2 is present.
only displayed if KK 2 is present.
For 3-circuit closed-loop control:
only displayed if an ambient sensor was also internally activated.
only displayed if the current control mode for KK 3 is “fixed value”.
only displayed if the current control mode for KK 3 is “ambient reference”.
only displayed if KK 3 is present.
only displayed if KK 3 is present.
