10
1 00589-002-1 Eyebolt 2
2 19100A033 Capscrew 2
3 04580-001-1 Drive Screw 4
4 14981-001-1 Pipe Plug 1
5 00064-003-1 Load Spring 1
6 00065-021-1 Upper Bearing 1
7 00065-018-1 Lower Bearing 1
8 04916-000-1 Shaft Seal S 1
04916-001-1 Shaft Seal (Carbide) Opt C 1
9 19103A045 Capscrew 4
10 01130-003-1 Machine Screw (Flat Head) 4
11 09995-000-2 Volute Case for S4S (shown) 1
09995-100-2 Volute Case for SB4S 1
12 10108-000-1 Impeller Washer 1
13 19101A003 Impeller Capscrew 1
14 08908-002-1 Key 1
15 09996-002-2 Seal Plate 1
16 00150-021-1 O-Ring SC 1
17 00517-007-1 Capscrew 4
18 00995-008-1 Lockwasher 4
19 00299-002-1 Stator Retaining Ring 1
20 05454-001-1 Roll Pin 1
21 13391-000-2 Motor Housing 1
22 00834-015-1 O-Ring SC 1
23 01329-025-5 Rotor w/Shaft (3 HP 1ø) 1
01329-025-5 Rotor w/Shaft (All 3ø) 1
01329-025-5 Rotor w/Shaft (5 HP 1ø) 1
24 24407C200 Stator (3 HP 1ø 230V) 1
24407C202 Stator (3 HP 3ø 230/460V) 1
24407C201 Stator (3 HP 3ø 200V) 1
24407C203 Stator (3 HP 3ø 575V) 1
24407C204 Stator (5 HP 1ø 230V) 1
24407C206 Stator (5 HP 3ø 230/460V) 1
24407C205 Stator (5 HP 3ø 200V) 1
24407C207 Stator (5 HP 3ø 575V) 1
24407C209 Stator (7-1/2 HP 3ø 200/230/460V) 1
24407C210 Stator (7-1/2 HP 3ø 575V) 1
25 02577-000-1 Wire Connector As Req.
Ref. Part Part
No. No. Description Qty.
12672A001 Wire Connector (14 & 16 wire size) As Req.
01006-001-1 Wire Connector (10 & 12 wire size) As Req.
26 152710335 35' Cord Assembly 14-4 1
152710305 35' Cord Assembly 12-4 1
152710315 35' Cord Assembly 10-4 1
152710325 35' Cord Assembly 8-4 SOOW 1
152710345 35' Cord Assembly 8-4 W 1
27 09978-007-2 Impeller (3 HP) 1
09978-008-2 Impeller (5 HP) 1
09978-009-2 Impeller (7-1/2 HP) 1
51700-061-7 Seal Kit
51700-361-7 Carbide Seal Kit
28 00356-004-2 Discharge Flange 1
29 010540001 Gasket 1
Ref. Part Part
No. No. Description Qty.
Ref. Part Part
No. No. Description Qty.
S4S/SB4S
Parts List
Notes: S — Parts in Seal Kit C — Parts in Carbide Seal Kit
— Fill Oil to above the Motor Windings
