Hydromatic S3S - Parts List

8
1 00589-002-1 Eyebolt 2
2 19100A033 Capscrew 2
3 04580-001-1 Drive Screw 4
4 14981-001-1 Pipe Plug 1
5 00064-003-1 Load Spring 1
6 00065-021-1 Upper Bearing 1
7 00065-027-1 Lower Bearing 1
8 00300-000-1 Shaft Seal S 1
00696-000-1 Shaft Seal (Carbide) Opt C 1
9 19103A045 Capscrew 4
10 01130-003-1 Machine Screw (Flat Head) 4
11 09947-000-2 Volute Case for S3S (shown) 1
09947-100-2 Volute Case for SB3S 1
12 10012-000-1 Impeller Washer 1
13 19100A003 Impeller Capscrew 1
14 10102-001-1 Key 1
15 09952-002-2 Seal Plate 1
16 00150-021-1 O-Ring SC 1
17 00517-007-1 Capscrew 4
18 00995-008-1 Lockwasher 4
19 00299-002-1 Stator Retaining Ring 1
20 09927-008-2 Impeller (1-1/2 HP) 1
09927-009-2 Impeller (2 HP) 1
09927-016-2 Impeller (3 HP) 1
21 00740-019-5 Rotor w/Shaft (1-1/2 & 2 HP 1ø) 1
7773-018-5 Rotor w/Shaft (2 HP, 1-1/2 HP 3ø) 1
01329-024-5 Rotor w/Shaft (3 HP 1ø) 1
01329-024-5 Rotor w/Shaft (3 HP 3ø) 1
22 24407C215 Stator (1-1/2 & 2 HP 1ø 230V) 1
24407C217 Stator (1-1/2 & 2 HP 3ø 230/460V) 1
24407C216 Stator (1-1/2 & 2 HP 3ø 200V) 1
24407C218 Stator (1-1/2 & 2 HP 3ø 575V) 1
24407C200 Stator (3 HP 1ø 230V) 1
24407C202 Stator (3 HP 3ø 230/460V) 1
Ref. Part Part
No. No. Description Qty.
24407C201 Stator (3 HP 3ø 200V) 1
24407C203 Stator (3 HP 3ø 575V) 1
23 00736-001-1 Spacer Ring (1-1/2 & 2 HP 1ø) 1
00736-000-1 Spacer Ring (1-1/2 & 2 HP 3ø) 1
24 12672A001 Wire Connector (all 1ø & 200/575V 3ø) 3
00282-001-1 Wire Connector (230/460V 3ø) 6
25 05454-001-1 Roll Pin 1
26 13391-000-2 Motor Housing 1
27 00834-015-1 O-Ring SC 1
28 152710335 35' Cord Assembly 14-4 1
152710305 35' Cord Assembly 12-4 1
152710315 35' Cord Assembly 10-4 1
51700-060-7 Seal Kit
51700-360-7 Carbide Seal Kit
00356-000-2 Discharge Flange 1
Notes: S — Parts in Seal Kit C — Parts in Carbide Seal Kit
— Fill Oil to above the Motor Windings
Ref. Part Part
No. No. Description Qty.
Ref. Part Part
No. No. Description Qty.
S3S/SB3S
Parts List
