10
1 10894-029-5 Cord Cap Assy. 35' dual 10/4 1
10894-005-5 Cord Cap Assy. 50' dual 10/4 1
10894-030-5 Cord Cap Assy. 35' dual 8/4 1
10894-010-5 Cord Cap Assy. 50' dual 8/4 1
2 00557-000-1
Connector 200/230/1/60 & 200/575/3/60
3
(3/4–5 HP)
00853-000-1 Connector 230/460/3/60 (1-1/2–5 HP)4
02494-000-1
C
onnector 200/230/460/575/3/60 (7-1⁄2 HP)
4
3 00834-008-1 O-Ring SC 1
4 10898-000-1 Connector 4
5 10899-000-1 Connector 9
6 05454-001-1 Roll Pin 1
7 00299-002-1 Stator Holding Ring 1
8 00065-020-1 Lower Bearing 1
9 00150-020-1 O-Ring SC 1
10 10900-001-5 Resistor Assy 1
11 10901-000-1 Terminal Seal Failure 2
12 00119-016-1 Pipe Plug 2
14 00150-011-1 O-Ring SC 1
15 00239-007-1 Bolt 4
16 00150-023-1 O-Ring SC 1
17 10753-000-2 Seal Plate 1
18 07992-021-2 Impeller 7.65" dia. 1
07992-001-2 Impeller 7.50" dia. 1
07992-023-2 Impeller 6.90" dia. 1
07992-025-2 Impeller 6.37" dia. 1
07992-014-2 Impeller 6.29" dia. 1
07992-016-2 Impeller 5.70" dia. 1
07992-027-2 Impeller 5.54" dia. 1
19 00238-006-1 Capscrew, SST 3
20 08422-001-1 Washer 1
21 00556-003-1 Capcrew SST 1
22 4906-001-3 Wear Ring 1
23 04916-000-1 Lower Seal (ceramic) std. S 1
04916-001-1 Lower Seal (carbide) opt. C 1
24 07993-001-5 Volute w/Wearing Ring 1
25 00517-007-1 Capscrew SST 3
26 00975-003-1 Retainer Ring 1
27 10743-000-2 Bearing Housing 1
28 00920-001-1 Upper Seal SC 1
29 00568-007-1 Capscrew 4
31 00517-008-1 Capscrew 4
32 24407C223 Stator 3/4–1 HP 230/1/60 1150 1
14715-203-1 Stator 3/4–1 HP 200/1/60 1150 1
24407C225 Stator 3/4–1 HP 230/460/3/60 1150 1
24407C224 Stator 3/4–1 HP 200/3/60 1150 1
24407C226 Stator 3/4–1 HP 575/3/60 1150 1
24407C231 Stator 1-1/2–2 HP 230/1/60 1150 1
14717-203-1 Stator 1-1/2–2 HP 200/1/60 1150 1
24407C233
Stator 1-
1/2
–2 HP 230/460/3/60 1150
1
32 24407C232 Stator 1-1/2–2 HP 200/3/60 1150 1
24407C234 Stator 1-1/2–2 HP 575/3/60 1150 1
24407C215 Stator 2 HP 230/1/60 1750 1
14696-203-1 Stator 2 HP 200/1/60 1750 1
24407C217 Stator 2 HP 230/460/3/60 1750 1
24407C216 Stator 2 HP 200/3/60 1750 1
24407C218 Stator 2 HP 575/3/60 1750 1
24407C200 Stator 3 HP 230/1/60 1750 1
14698-203-1 Stator 3 HP 200/1/60 1750 1
24407C202 Stator 3 HP 230/460/3/60 1750 1
24407C201 Stator 3 HP 200/3/60 1750 1
24407C203 Stator 3 HP 575/3/60 1750 1
24407C204 Stator 5 HP 230/1/60 1750 1
24407C206 Stator 5 HP 230/460/3/60 1750 1
24407C205 Stator 5 HP 200/3/60 1750 1
24407C207 Stator 5 HP 575/3/60 1750 1
Ref. Part Part
No. No. Description Qty.
24407C209 Stator 7-1/2 HP 230/460/3/60 1750 1
24407C208 Stator 7-1/2 HP 200/3/60 1750 1
24407C210 Stator 7-1/2 HP 575/3/60 1750 1
33 07774-014-5 Rotor & Shaft 3/4–1 HP 1ph. 1150 1
07773-014-5 Rotor & Shaft 3/4–1 HP 3 ph. 1150 1
1329-017-5 Rotor & Shaft 1-1/2–2 HP 1 ph. 1150 1
00740-017-5 Rotor & Shaft 1-1/2–2 HP 3 ph. 1150 1
00740-017-5 Rotor & Shaft 2 HP 1 ph. 1750 1
00741-012-5 Rotor & Shaft 2 HP 3 ph. 1750 1
01329-017-5 Rotor & Shaft 3 HP 1 ph. 1750 1
01329-017-5 Rotor & Shaft 3–5 HP 3 ph. 1750 1
01329-017-5 Rotor & Shaft 7-1/2 HP 3 ph. 1750 1
34 10765-003-2 Housing 3/4–1 HP 3ph. 1150, 1
2
HP 3 ph. 1750
10765-002-2 Housing (all others) 1
36 00736-001-1 Spacer 3/4–1-1/2 HP 3 ph. 1150, 1
2 HP 1 ph./3 ph. 1750
00736-002-1 Spacer 3/4–1 HP 1 ph. 1150 1
37 00065-021-1 Upper Bearing 1
38 00064-003-1 Load Spring 1
39 01032-002-1 Nut 2
40 00589-002-1 Bolt 2
41 10895-000-5 Conn. Box 230/460/3/60 1
10895-001-5 Conn. Box 200/230/1/60, 1
200/575/3/60
42 00834-013-1 O-Ring SC 1
43 00101-007-1 Capscrew 2
44 00238-006-1 Capscrew 2
45 04580-001-1 Drivescrew A/R
48 00995-008-1 Washer 4
51700-057-7 Seal Kit
51700-357-7 Carbide Seal Kit
49 24709110000 Paraffinic Oil
Notes: S — Parts in Seal Kit C — Parts in Carbide Seal Kit
— Amount of oil required varies between 92-124 oz. depending on stator size, fill to above motor windings.
ORDERING REPLACEMENT PARTS: Product improvements are made from time to time. The latest part design will be fur nished
a
s long as it is in ter change able with the old part.When ordering re place ment parts, always furnish the fol low ing information: (1)
pump serial num ber, (2) pump model and size, (3) part description, (4) part number, (5) im pel ler diameter (if ordering impeller),
(6) quan ti ty required, and (7) shipping instructions.
Ref. Part Part
No. No. Description Qty.
Ref. Part Part
No. No. Description Qty.
S4NX
Parts List
For use with product built with Regal Beloit/Marathon motor.
