STEP FIVE - INSTALLING VALVE (continued)
• Once valve is in place, hold clamp as
shown and position clamp around lip of
tank and over edge of valve.
2 long screws and nuts are provided
to secure clamp. (Fig. 17)
• Clean off any sand or debris on top of filter
and position valve over the opening of the
standpipe. Valve will slide ONTO standpipe
when positioned properly in tank (Fig. 15).
Push down firmly to make sure valve slides
on all the way.
• Place valve so that pump port is directly
over the pump. (Fig. 16)
Fig. 17
NOTE:
You CANNOT pull
standpipe up to secure the
valve. Pulling up can damage the filter
and cause sand to get sent back with
water flow into the pool!
Fig. 15
Fig. 16
8
