User Guide Oxymatic Basic
Rev.Apr 2013
Hydrover Water Solutions S..L.U.
18
5.3. How to see the configuration and pH set point’s
1. Turn the computer OFF.
2. In the 8 LED for OXY and ION are the positions of the machine configuration switches. On = ON, OFF =OFF.
3. Then the light is turned on first position in which this set points1 that is OFF.
4. Then turn on the light's 2 set point which is 100%.
5. Then all the lights off from the computer OFF.
6. INSTALLATIONANDPUTTINGINMARCH,STEPWISE
In summary Hydrover recommends that the following steps and recommendation are followed in a chronological
way. This will ensure the correct installation of the equipment: THE MANUAL OF INSTRUCTIONS READS
1. The location adapted in the pipeline – take sufficient time to carefully install the chamber
portaelectrodos in the by-pass (three manual valves) to the exit of the filter in the drive and before the
heat interchanger. In case that there is a heat interchanger and there was no space before, to put the
chamber later but it is necessary to leave 1,5 meters of distance, the chamber is prepared to support
50 º C but not more. To carry out the installation of plumbing. Entry - electrode OXY and portasondas.
Exit - electrode charges and injectors. While the glue dries off.
2. To establish a suitable wall and location to install the unit of control, this should be close to the
chamber – fix to the preferred location
3. The hang rhe dosing pump oh pH close to the chamber and above the container of pH reductor
4. To put the electrodes in order of entry and exit carefully.
When the glue is dry
5. The recirculation is set to work with three open valves, later close the valve of the bypass and allow
water into the chamber. In the case of water escaping press the elements carefully. (An allen key is
required for the stoppers and a grifa for the rosca of the electrodes).
6. The air Purges with the top buttons of the chamber
7. With the recirculation in action and the bypass closed follow the next steps:
a) To remove the hood to the probe of pH and to introduce with carries??? probes in their place. The
cable of the probe plugs into the control unit.
b) Electrical wiring to the control unit - elements OXI-ION-alimentación etc (ready wired from the
factory).
c) Installation of pipes.
d) White pipe: aspiration acid. From the entry of the (left) bomb to the carafe of minorador ó
augmenting of pH another end to remove the lid to a carafe of acid, to make a hole of the size of
the pipe introduce the pipe and to another side of the lid to place the system of aspiration
(included), to put the pipe in the carafe and to close the lid. To try comes to the bottom.
e) Transparent Pipe: injection from the right part of the bomb dosificator to the chamber in his place.
f) Once all the necessary connections have been made open the bypass and to start up the
equipment.
g) The probe of pH has to be calibrated.
h) Turn to auto position.
i) Verify that all the elements work correctly
j) To measure the copper and it
