HYENA E-BIKE SYSTEMS
8
Fasten the screws (maximum torque 4.5 Nm).
Install and fasten the cassette sprocket and cassette
locking ring (right side).
Install the motor (rear wheel).
Insert the torque washer through the motor shaft
(washer bulge aligns with the flat side of the shaft), then
fasten the flange nut (maximum torque 11 Nm).
Completed.
STEP
3
STEP
4
STEP
5
STEP
6
STEP
7
