HYENA E-BIKE SYSTEMS
1
Introduction
This manual is intended primarily for the trained technician to install, disassemble, or maintain the Hyena e-bike system only.
Please read all the safety warnings and instructions carefully. Failure to follow the warnings and instructions may result in
death or severe injuries. Save this manual for future reference.
Product Features
Product Description
The MRC-E250 rear hub motor provides power for the e-bike. It features an amazingly lightweight, extra small size, and is
maintenance-free.
Parts Description
Item
Description
Item
Description
A
M6 Hex socket security bolt
D
Sticker (remove on install)
B
Anti-rotation flange nut
E
Cable (connect to controller)
C
M5 button-head hex socket screw
F
Cassette mounting base
A
D
E
B
A
B
C
F
