Hyena MRC-E250 - Technical Data; Function; Characteristic

HYENA E-BIKE SYSTEMS
4
Technical Data
Function
Rated power
250 W
Rated voltage
36 V
Wheel size
26 to 28 inches
Max. torque
40 Nm
No-load RPM
≥ 270 RPM
w/o loading
Max. current at n0 RPM
≤ 1.7 A
w/o loading
Max. noise at n0 RPM
< 60 dB
w/o loading
Rated RPM
250 ±5% RPM
Max. efficiency
≥ 80 %
Weight
2.2 Kg
Waterproof level
IP54
Hall sensor
Yes
Speed sensor
Yes
1 Magnet
Characteristic
Protocol
N/A
Control type
Sine wave
Reduction ratio
1:12.6
Operating temperature
-10℃ to +50℃ 80%RH
Storage temperature
-20℃ to +70℃ 80%RH
Insulation
≥ 50 MΩ
