Legend for Figure 3
Legend
Item
Code Description Value Connector Location
1. BATTERY DISCONNECT
SWITCH
-- -- --
2. BATTERY DISCONNECT
SWITCH LOCK
-- -- --
3. BATTERY -- -- --
4. POWERBOARD -- -- --
5. F1 ALTERNATOR 125A TS15/TS16 [37,A]
6. R1 RELAY GRID HEATER 200A TS18/
CPS166
[34,H]
7. F2 CAB SUPPLY 125A TS10/TS01 [21,B]
8. F4 DEF HOSE HEATING 15A CPS166 [51,D]
9. F3 GRID HEATER 150A F3 [34,H]
10. F5 SPARE 10A CPS166 [52,C]
11. F6 DEF MODULE HEATER 10A CPS166 [52,D]
12. F7 SPARE 7.5A CPS166 [53,C]
13. F8 SPARE 10A CPS166 [52,C]
14. F11 SPARE 15A CPS166 [53,C]
15. R4 RELAY DEF HOSE 3 -- CPS166 [50,C]
16. R5 RELAY DEF MODULE HEATER -- CPS166 [52,C]
17. R3 RELAY DEF HOSE 2 -- CPS166 [51,D]
18. R2 RELAY DEF HOSE 1 -- CPS166 [51,C]
19. F10 ENGINE ECM SUPPLY 30A CPS178 [32,H]
20. F9 CAB TILT 30A CPS178 [104,G]
