SYMBOL DEFINITIONS
See Table 2 for description of symbol definitions.
Table 2. Symbol Definitions
Symbol Name Definition
Type S Identifies information
for UL Safety rated
trucks. Applicable
trucks are rated for GS,
LPS, and DS depending
on fuel type.
Arrow Symbol
Go to specified page of
schematic, located in
lower right corner in the
hexagon symbol.
-----X Go to specified sheet of
diagram. Sheet number
is located in lower right
corner of figure.
DIAGRAMS MANUAL APPLICATIONS
See Table 3 for the correct diagrams service manual for your lift truck.
Table 3. 1-9 Ton Diagrams Manual Applications
Unit Code Production Date
Electrical
Schematic
Wiring
Diagram
Diagrams Manual
Number
E010, F001
Prior to August 2008 8525590 8516519 8000 SRM 1152
August, 2008 to April, 2009 1665405 1665404 8000 SRM 1387
May, 2009 to December
2012
1688540 1688539 8000 SRM 1409
January, 2013 to April 2014 4051618 4051617 8000 SRM 1585
April, 2014 ===> 4100474 4100473 8000 SRM 1689
F187, L177
Prior to August 2008 8525590 8516519 8000 SRM 1152
August, 2008 to April, 2009 1665405 1665404 8000 SRM 1387
May, 2009 to December
2012
1688540 1688539 8000 SRM 1409
January, 2013 ===> 4051618 4051617 8000 SRM 1585
G004
Prior to August 2008 8525590 8516519 8000 SRM 1152
August, 2008 to December
2009
1665405 1665404 8000 SRM 1387
January 2010 to January
2012
1688540 1688539 8000 SRM 1409
January 2012 ===> 4051618 4051617 8000 SRM 1585
General Information About Diagrams and Schematics 8000 SRM 1904
2
