Switching Power Supply
4
General Description
As an advanced switching power supply with novel appearance, it can
work with two power modes: mains supply and the backup battery.
When one mode fails, the other will work automatically to ensure normal
performance. What it brings to user is not only simple and efficient
operation from oating charge, but also strong protection against polarity
reverse and overcharge. Please note that this product is designed for
Hytera repeater and high-power communication devices.
Status Indication
The LED indicator will help you easily identify current power supply
mode.
LED Indicator Power Mode
Green LED glows. Mains supply
Blue LED glows. Battery
Red LED glows. Battery is working but runs low.
Operation Guide
Installation Procedures
1. Connecting the repeater.
(1) Install this product onto a at and stable bench.
(2) Connect the power cord of repeater to the Output Connector
properly: RED pole for anode and BLACK pole for cathode. Always
ensure the polarity is correct.
2. Connecting the AC power cord.
(1) Turn this product off.
(2) Plug one end of AC power cord into AC power port and the other end
into AC outlet.
(3) Turn on the product and the LED glows green.
