SM16 Series Palm Microphone Owner's Manual
5
Product Controls
Before Use
Securing the Microphone Hanger to the Dashboard
1. Place the microphone hanger in the desired location close
to the mobile radio (e.g. the dashboard as shown in the
fi gure below).
2. Insert a screw into each hole and tighten it.
PTT Key
Connector
Microphone
Hook Key
Dashboard
Screws
Microphone Hanger
