4
Rear Panel Overview
①
15PIN (for external expansion)
②
External Speaker Jack
Used to connect external speaker and only available for the plug of 3.5 mm
③
Power Inlet
Adopt HYT-authorized DC power cable and 13.6 V DC power.
④
Antenna Pedestal
Used to connect external antenna.
Microphone
