Hyundai Matrix User Manual

9
VEHICLE SPECIFICATIONS
3
DIESEL
1.5 4Cylinder in-line DOHC
740 ± 100
-
-
-
-
-
-
Auto Lash
Auto Lash
-
1 - 3 - 4 - 2
ENGINE
J070A04FC-GAT
NGK
CHAMPION
NGK
CHAMPION
Unleaded
Leaded
Unleaded
Leaded
For adjusting
For checking
Engine Type
Idle Speed (RPM)
Spark Plug
Spark Plug Gap
Valve Clearance
(Cold engine:20 ± 5°C)
Ignition Timing
Firing Order
ITEMS
A/CON OFF
A/CON ON
GASOLINE
1.6/1.8 4Cylinder in-line DOHC
800 ± 100 (1.6L), 750 ± 100 (1.8 L)
800 ± 100 (1.6L), 800 ± 100 (1.8 L)
BKR5ES-11
RC10YC4
BKR5ES
RC10YC
1.0 ~ 1.1 mm (0.039 ~ 0.043 in.)
0.7 ~ 0.8 mm (0.028 ~ 0.032 in.)
Auto Lash (1.6 DOHC)
0.17 ~ 0.23 mm (0.0067 ~ 0.0091 in.) (1.8DOHC)
Auto Lash (1.6 DOHC)
0.25 ~ 0.31 mm (0.0098 ~ 0.0122 in.) (1.8 DOHC)
Auto Lash (1.6 DOHC)
0.12 ~ 0.28 mm (0.0047 ~ 0.011 in.) (1.8 DOHC)
Auto Lash (1.6 DOHC)
0.20 ~ 0.38 mm (0.0079 ~ 0.015 in.) (1.8 DOHC)
BTDC 5° ± 5° (1.6L), BTDC 7° ± 5° (1.8L)
1 - 3 - 4 - 2
Intake
Exhaust
Intake
Exhaust
