PAGE 25
8. TROUBLE SHOOTING & SPECIFICATION
Specications
Please note that the maximum range is based on an ambient temperature of 20°C, a
75kg driver, a brand new and fully charged battery, and a constant driving speed of 4/5
mph with 70% battery power discharged.
NOTE: Specications are subject to change without notice.
Item
Dimension (L×W×H )
Weight:
Batteries
Without batteries
Seat weight
Total weight
Battery
Caster wheel
Rear wheel
Motor
Charger
MAX. Speed
Climbing angle
Controller
Anti-tip wheel
Charging time, hours
Weight capacity
Crest CSS
850×585×885mm
33.5×23×34.8 inches
30.8lbs / 14 Kg
72.6lbs / 33 Kg
15.8lbs / 7.2 Kg
120lbs / 54.2 Kg
20AH/12Vx2
8“×2 Solid / 200x50mm
9“×3.3 Solid / 230x75mm
250W/3000RPM
4 mph / 6.4Km/h
6°
Dynamic Shark 40A
2.36” /50 mm
>8 hours
136 kg / 300lbs
