Chapter 3 Technical Information
Specifications
LCD Panel
Size 19" (48cm)
Display Type Active matrix color TFT LCD
Resolution 1280 x 1024
0.294“ x 0.294“
0.294“ x 0.294“
Display Area (mm) 14.82” x 11.85”(H x V)
Display Colors
16.2M with FRC or Dithering
Video
Input Signal
Input Impedance
Polarity
Amplitude
Multi-mode Supported
Analog RGB 0.7Vp-p.
75 Ohm ± 2%
Positive, Negative
0 - 0.7 ± 0.05 Vp
Horizontal Frequency: 24 ~ 80 kHz
Vertical Frequency: 56 ~ 75 Hz
Digital TMDS
TMDS
24~80KHz
56~75 Hz
Control
Power switch (hard and soft types) On/Off switch with LED indicator
AUDIO
INPUT
OUTPUT
500m Vrms
0.5W + 0.5W
OSD
Brightness
Contrast
Horizontal Position
Vertical Position
Phase
Clock
OSD Format
Digital
Digital
Digital
Digital
Digital
Digital
26 characters x 15 rows
Power Management
Mode Power Consumption* AC Input LED Color
On 55 W maximum 240 VAC Blue
Off 2 W maximum 240 VAC Yellow
Soft switch off 2 W maximum 240 VAC Dark
Disconnected 2 W maximum 240 VAC
Yellow: Standby, Suspend, Off
Dark: DC Power of
* Meeting VESA DPMS requirements measured from AC Input end of AC power cord.
Sync Input
Analog Digital
Signal
Separate TTL compatible horizontal and
vertical synchronization
TMDS
Polarity Positive and negative
--
Plug & Play
Supports VESA DDC2B functions
External Connection
Power Input (AC input)
AC socket
Video Cable
15-pin D-sub connector/Monitor-to-PC DVI-D Cable (optional)
Audio Cable
Stereo Jack
Environment
Operating Condition:
Temperature 5°C to 40°C/41°F to 104°F
