I-Inc CY199D - Pin Assignment

8
Relative Humidity 20% to 80%
Storage Condition:
Temperature -20°C to 60° C/-4°F to140° F
Relative Humidity 5% to 85%
Power Supply (AC Input)
Input Voltage
Single phase, 100 ~ 240VAC, 50 / 60 Hz
Input Current
1.2 A maximum
Size and Weight
Dimensions
16.6” (W) x 16.8”(H) x 8.7” (D) mm
Net Weight
20.9 lbs.
Gross Weight
24.2 lbs.
Pin Assignment
Signal Signal
PIN Description PIN Description
1
5
6
10
11
15
1
2
3
4
5
6
7
8
Red
Green
Blue
Digital GND
Digital GND
Red Rtn
Green Rtn
Blue Rtn
9
10
11
12
13
14
15
+5V
Hot Plug Detect
NC
SDA
H. Sync.
V. Sync.
SCL
For Digital DVI-D connector
Signal Signal Signal
PIN Description PIN Description PIN Description
1 RX2- 10 RX1+ 19
Shield for TMDS
Channel 0
2 RX2+ 11
Shield for TMDS
Channel 1
20 NC
3
Shield for TMDS
Channel 2
12 NC 21 NC
4 NC 13 NC 22
Shield for TMDS
Channel clock
5 NC 14 +5V 23 RXC+
6 SCL 15 Hot Plug Detect 24 RXC-
7 SDA 16 HPD C5 NC
8 NC 17 RX0- C6 NC
9
17
24
16
C5/C
6
1
8
9 RX1- 18 RX0+
