I-Tech LaMagneto - Technical Characteristics

I.A.C.E.R. Srl 8 MNPG262-02
Technical characteristics
Power supply
Pow. UES36LCP-150200SPA, out 15VDC-2A
Max. current consumption
1 A
Insulation class (CEI EN 60601-1)
II
Applied part (CEI EN 60601-1)
BF
Dimensions (length x width x
height)(mm)
180x110x50
Intensity of the field
Adjustable with increasing scale up to 150 Gauss
(per channel).
Frequency of the square wave
1-100 Hz
Therapy time
User-settable
The maximum magnetic field intensity is 150 Gauss per channel
with a professional applicator with a pair of solenoids (optional
accessory).
The values of intensity, frequency and time are supplied with an
accuracy of ± 20%.
Ambient operating conditions:
temperature from +5 to + 30°C
relative humidity from 15 to 93%
pressure from 700 to 1060 hPa
