21 INPUT
Connects an instrument, such as a guitar or the output of another effect
device, via a shielded cable� Plugging into this jack automatically puts
power to the unit�
22 EXT DC input
Be sure to use a center negative external DC 9V power supply�
(AC/DC adapter etc�) When using this jack, the internal battery is switched
off�
23
REMOTE
Connect the Ibanez IFS2L footswitch (sold separately)� You can turn the
PRE BOOST and the 5-BAND EQ on/off remotely� When the footswitch is
connected, the toggle switches on the pedal for the PRE BOOST and the
5-BAND EQ ON/OFF are disabled�
24
OUTPUT
Connects an amp or another effect pedal, via a shielded cable�
