10
NOISE GATE
15 On/off switch
Turns the NOISE GATE function on/off�
16
Indicator red
Red LED lights when the NOISE GATE is turned on�
17
Indicator green
Green LED will light up when the gate is working�
18
GATE
Controls the threshold level that engages the mute circuitry�
This sets the limit for when the gate will take effect and start to decrease
or mute the signal� Turning the knob clockwise, increases the threshold
which means the signal will be muted faster�
BYPASS
19 On/off switch
True bypass switch turns the PENTATONE PREAMP on/off�
20
Indicator
Red LED lights when the PENTATONE PREAMP is turned on�
