TB225 PARTS LIST
3200714 AA 01 C.F. RESISTOR 2.4 KOHM 1/6W R148 1
3200563 AA 01 C.F. RESISTOR 2.7 KOHM 1/6W R151 1
3200291 AA 01 C.F. RESISTOR 4.7 KOHM 1/6W
R12,14,15,28,33,55,56,64,149,153,164
,181,182,183,184, 15
3200904 AA 01 C.F. RESISTOR 5.1 KOHM 1/6W R109,110 2
3200422 AA 01 C.F. RESISTOR 6.2 KOHM 1/6W R75,76 2
3200423 AA 01 C.F. RESISTOR 8.2 KOHM 1/6W R17,25,36,44, 4
3200721 AA 01 C.F. RESISTOR 9.1 KOHM 1/6W R32 1
3200293 AA 01 C.F. RESISTOR 10 KOHM 1/6W
R20,23,42,43,47,66,67,68,115,116,127
,128,129,131,132,133,134,137,139,154
,155,168,169,170,171,172,173,174. 28
3200294 AA 01 C.F. RESISTOR 15 KOHM 1/6W R65,113,114 3
3200427 AA 01 C.F. RESISTOR 22 KOHM 1/6W R49,50,52,61,62,121,122,162 8
3200428 AA 01 C.F. RESISTOR 27 KOHM 1/6W R119,120 2
3200295 AA 01 C.F. RESISTOR 33 KOHM 1/6W R77,78,140,152 4
3200430 AA 01 C.F. RESISTOR 47 KOHM 1/6W
R10,16,35,59,71,72,142,157,158.159,1
79,180, 12
3200914 AA 01 C.F. RESISTOR 51 KOHM 1/6W R166 1
3200915 AA 01 C.F. RESISTOR 75 KOHM 1/6W R145 1
3200916 AA 01 C.F. RESISTOR 91 KOHM 1/6W R146 1
3200296 AA 01 C.F. RESISTOR 100 KOHM 1/6W
R5,7,26,30,45,48,57,58,130,135,136,1
41,144,156,160,161,163,175,176 19
3200432 AA 01 C.F. RESISTOR 120 KOHM 1/6W R117,118 2
3200736 AA 01 C.F. RESISTOR 180 KOHM 1/6W R150 1
3200434 AA 01 C.F. RESISTOR 220 KOHM 1/6W R18,21,40,41,51,147 6
3200921 AA 01 C.F. RESISTOR 750 KOHM 1/6W R138 1
3200299 AA 01 C.F. RESISTOR 1 MOHM 1/6W R2,8,27,31,46,167, 6
3200923 AA 01 C.F.RES. FUSIBLE 100 OHM 1/2W R89.90,99,100 4
3200441 AA 01 MO RESISTOR 10OHM 1W J R83,84,123,124 4
3200746 AA 01 MO RESISTOR 0.5OHM 2W J R95,96,101,102 4
3200444 AA 01 MO RESISTOR 470OHM 2W J R125,126 2
3200445 AA 01 CERAMIC CAP 5 PF 50V C70,71 2
3200446 AA 01 CERAMIC CAP 10 PF 50V C74,75,80,81 4
3200749 AA 01 CERAMIC CAP 22 PF 50V C102 1
3200302 AA 01 CERAMIC CAP 33 PF 50V C127,128 2
3200303 AA 01 CERAMIC CAP 47 PF 50V C3,64,76,77,82,83,117,118, 8
3200042 AA 01 CERAMIC CAP 100 PF 50V C24,42,108,111,129,130, 6
3200304 AA 01 CERAMIC CAP 200 PF 50V C68,69 2
3200043 AA 01 CERAMIC CAP 220 PF 50V C36 1
3200594 AA 01 CERAMIC CAP 330 PF 50V C28, 1
3200306 AA 01 CERAMIC CAP 470 PF 50V C94 1
3200307 AA 01 CERAMIC CAP 560 PF 50V C107 1
3200757 AA 01 CERAMIC CAP 680 PF 50V C5,11 2
3200308 AA 01 CERAMIC CAP 104 PF 50V
C12,13,17,18,33,34,35,49,50,55,56,57
,60,61,65,88,89,89,95,105,113,115,11
6,131,132,141,143,144, 27
3200044 AA 01 LINE CROSS CAP 103PF/400VAC C104 1
3200133 AA 01 MYLAR CAP 102 50V J C21,39, 2
3200942 AA 01 MYLAR CAP 182 50V J C114 1
3200311 AA 01 MYLAR CAP 272 50V J C38 1
3200944 AA 01 MYLAR CAP 302 50V J C92, 1
3200312 AA 01 MYLAR CAP 472 50V J C20, 1
3200946 AA 01 MYLAR CAP 822 50V J C93 1
3200134 AA 01 MYLAR CAP 103 50V J C100,101 2
3200316 AA 01 MYLAR CAP 273 50V J C8, 1
3200458 AA 01 MYLAR CAP 393 50V J C16,23 2
3200047 AA 01 MYLAR CAP 473 50V J C1,6,15,27,30,31,45,72,73,90,91,112 12
3200951 AA 01 MYLAR CAP 823 50V J C41,99 2
3200048 AA 01 MYLAR CAP 104 50V J C40,62,133,134,135,136 6
