TB225 PARTS LIST
3200319 AA 01 ELECTRO CAP 0.1UF 50V(NP) C22 1
3200321 AA 01 ELECTRO CAP 0.47UF 50V(NP) C32,46, 2
3200322 AA 01 ELECTRO CAP 1UF 50V(NP) C4,7,9,14,19,37,58,66,67,96, 10
3200956 AA 01 ELECTRO CAP 2.2UF 50V(NP) C106, 1
3200323 AA 01 ELECTRO CAP 3.3UF 50V(NP) C121,122 2
3200958 AA 01 ELECTRO CAP 10UF 16V(NP)
C2,25,26,29,43,44,59,63,109,110,119,
120,123,124,125,126, 16
3200324 AA 01 ELECTRO CAP 22UF 25V(NP) C10, 1
3200139 AA 01 ELECTRO CAP 1UF 50V C97,98 2
3200140 AA 01 ELECTRO CAP 4.7UF 50V C84,85,86,87 4
3200141 AA 01 ELECTRO CAP 10UF 50V C103142 2
3200963 AA 01 ELECTRO CAP 22UF 50V C78,79, 2
3200787 AA 01 ELECTRO CAP 100UF 25V C51,52,53,54 4
3200471 AA 01 ELECTRO CAP 100UF 50V C137,138,139,140 4
3200966 AA 01 ELECTRO CAP 3300UF 50V (SHL) C47,48 2
3200328 AA 01 CONNECTOR 5267-02P CW3,4,15,17,18, 5
3200968 AA 01 CONNECTOR 5267-03P CW5,16 2
3200329 AA 01 CONNECTOR CW1143-03 CW2 1
3200482 AA 01 SPEAKER PSR-013L SPK1,2 2
3200971 AA 01 HEATING TUBE DIA10 TUBE 20mm POWER SWITCH WIRING 6
3200334 AA 01 CLOSE & CONNECT DIA4.5 UL AC PRIMARY CONNECTION 1
3200069 AA 01 STRAIN RELIEF SR6N-4
POWERTRANS 1'st / 2'nd x 2PCS , SPK
WIRE x1PCS 3
3200974 AA 01 PCB ASSY TB225 TB-225 MAIN BOARD 1
3200975 AA 01 AC CORD DETACHED 100V(JAPAN) 1
3200976 AA 01 AC CORD DETACHED 120V(USA/CANADA) 1
3200977 AA 01 AC CORD DETACHED 230V(EUROPEAN) 1
3200978 AA 01 AC CORD DETACHED 240V(AUSTRALIA ) 1
3200979 AA 01 MAIN CHASSIS EGI 1.2T 1
3200980 AA 01 WOODEN CABINET PB20T 1
3200981 AA 01 FRONT PANEL AL 0.5T 1
3200982 AA 01 REAR PANEL PVC 0.5T 1
3200490 AA 01 CORNER(FRONT) MA CORNER TB25 4
3200343 AA 01 CORNER(REAR) MA CORNER TB25 4
3200085 AA 01 FOOT ASS'Y 4
3200986 AA 01 HANDLE ASS'Y BLACK, 220mm 1
3200087 AA 01 CONTROL KNOB BLACK+WHITE 13
3200988 AA 01 HEAT SINK AL 1
3200989 AA 01 HEAT SINK BRKT EGI 1.0T 2
3200090 AA 01 LOGO (SILVER) ABS 1
3200091 AA 01 PUSH KNOB BLACK+WHITE 3
3200992 AA 01 INSTRUCTION MANUAL TB225 1
3200993 AA 01 BIAS TR BRKT 1.0T 2
3200994 AA 01 CORD BUSHING TB225 3
3200093 AA 01 STAR WASHER DIA4 2
3200094 AA 01 GND LABEL 2
3200997 AA 01 SPEAKER LABEL PJ 30G 2
3200998 AA 01 CARTON BOX DW-2 TB225 1
3200999 AA 01 SNOW PAD TB225 8
3201000 AA 01 WIRE CLAMP 2
3200359 AA 01 FALT 280X17X1T 6
3201002 AA 01 HEAT SINK(B) 14.8X10.6X27L 2
3201003 AA 01 SCREW1 DIA4X10 TRU, BLACK GND:2 2
3201004 AA 01 SCREW2 DIA3X6 BH, BLACK, TTS HEAT SINK+CHASSIS:4,HEAT SINK BRKT:4 8
3200362 AA 01 SCREW3 M3X8,BH,ZN BIS TR:2,PCB:2 4
3201006 AA 01 SCREW4 M3X12 SW TR:2 4
3201007 AA 01 SCREW5 TAPPING DIA3X8L PCB+HEAT SINK:2 2
3201008 AA 01 SCREW6 M4X10L POWER TRANS:4 4
3201009 AA 01 SCREW7 TAPPING 1 DIA2.6X10,FH,BK LOGO:2,VENT COVER:4 6
