iBasso DX90 - Specifications

Specifications:
Line out:
Frequency Response: 17Hz~20KHz +/-0.1dB
S/N: -119dB +/-1dB
THD+N: 0.0015%
Crosstalk: 115dB (1KHz)
Output Level: 1.7Vrms (1kHz 0dB)
Headphne out:
Frequency Response: 17Hz~20KHz +/-0.1dB
THD+N: 0.0015% (32ohm load)
Output Level: 1.3Vrms(Low gain), 2.0Vrms(Mid gain), 2.8Vrms(High Gain)
S/N: -118dB +/-1dB(Low gain), -116dB +/-1dB(Mid gain), -115dB +/-1dB
(High Gain) (32ohm Load)
Crosstalk: 75dB (1KHz,32ohm Load)
Output Impedance: <0.1ohm
Play Time: 8hours
Battery Charge Time: 3hours with AC adapter, 5.5hours with PC USB port
On Board Flash: 8GB
Audio Formats Supported: APE, FLAC, WAV, WMA, AAC, ALAC, AIFF, OGG,
MP3, DSF
Case Dimension: 2.52W x 3.98L x 0.67H (inch)
64W x 100L x 17H (mm)
Weight: 140g or 4.94oz
DX90 User Guide
4
Names of Parts & Functions:
Coaxial Output Port
Micro USB Port
Micro SD Card Slot
