IBC AHU 800 - Page 32

An internal time delay is preset, enabling the W2 blower speed after a preset period of time. A jumper
between W1 and W2 will initialize this speed without the time delay.
Figure 23 Single-stage heating, on-demand heat source
30
Section: Installation
