An internal time delay is preset enabling the W2 blower speed after a preset time period. A
jumper between W1 and W2 will initialize this speed without the time delay.
Optional
Figure 25 Single-stage heating, single-stage cooling, fan control, on-demand heat source
32
Section: Installation
