6-3
DIAGRAMS
HC SERIES BOILERS HC 13-50, HC 15-95, HC 15-96, HC 20-125, HC 33-160
Diagram 6.1-2: Boiler assembly parts list (refer to Diagram 6.1-1 on opposite page)
Some parts are available in Kits.
Please visit www.ibcboiler.com
for more information.
ITEM NO. PART NO. DESCRIPTION QTY
10 240-067 IGNITOR 1
20 250-622 GASKET, IGNITOR 1
30 250-623 VIEWPORT HOLDER 1
40 250-624 GASKET, VIEWPORT HOLDER 1
50 250-625 GASKET, VIEWPORT GLASS 1
60 250-626 VIEWPORT GLASS 1
70 170-022 HEAT EXCHANGER, HC 95 1
80 250-688 GASKET, H.Ex., FRONT PANEL, DC/HC 95 1
90 180-114 BURNER 1
100 250-646 GASKET, BURNER 1
110 250-627 GASKET, FAN 1
115 XXX GASKET, FAN - DISCONTINUED MODEL
120 240-145 FAN, EBM 1
130 240-144 VENTURI, 500, DC/HC 95 1
135 250-732 GAS LINE, UPPER, DC/HC 95 1
140
180-095 ORIFICE, 505, NATURAL GAS, DC/HC 95
1
180-198 ORIFICE, 392, PROPANE, DC/HC 95
150 150-175 ORIFICE, O-RING 1
155 150-206 GASKET, GAS VALVE, INLET 1
160 180-097 GAS VALVE 1
170 240-069 GAS VALVE CABLE/IGNITION MODULE 1
180 250-628 GAS LINE, LOWER 1
190 250-634 GASKET, PUMP 2
200 180-098 PUMP 1
210 250-631 RETURN PIPE 1
220 500-073 DOOR ASSEMBLY, DC/HC 95 1
230
500-053 CONTROLLER ASSEMBLY, DC/HC 160
1500-071 CONTROLLER ASSEMBLY, HC 50
500-086 CONTROLLER ASSEMBLY, DC/HC 125
500-116 DC/HC CONTROLLER ASSEMBLY, DC/HC 95, 96 1
240 190-123 CONDENSATE PIPE ASSEMBLY 1
250 190-124 SEAL, COND. PIPE TO BOTTOM PAN 1
260 180-100 BOTTOM PAN, HEAT EXCHANGER 1
270 240-076 VENT HIGH LIMIT SWITCH 1
280 190-119 FITTING, 1/2" NPT-M 1
290 190-121 FITTING, 1" NPT-M 2
300 180-113 CONDENSATE TRAP, LONG, DC/HC 95, 96, 125, 160 1
310 250-638 CONDENSATE TRAP HOOK 1
320 240-072 WATER PRESSURE SENSOR TYPE LWCO 1
325 150-204 C-CLIP, WATER PRESSURE SENSOR 1
330 240-073 WATER TEMPERATURE SENSOR 2
335 150-221 CLIP, WATER TEMPERATURE SENSOR 2
340 250-632 SUPPLY PIPE 1
350 250-635 GASKET, SUPPLY PIPE 1
360 250-674 EXHAUST DUCT, INTERNAL, DC/HC 95 1
370 250-636 EXHAUST DUCT 1
380 250-637 INTAKE DUCT 1
not shown 210-035 EBM FAN POWER CABLE 1
