Qscan User’s Guide Version 1.4

Page 41

Proximity and iClass Input, Format # 1 Mask, Part 2*

X055 p3 ll3 p4 ll4 p5 ll5

p3 start position 00=ll3 is a constant

ll3 length or constant

p4 start position 00=ll4 is a constant

ll4 length or constant

p5 start position 00=ll5 is a constant

ll5 length or constant

All parameters have the same usage as the prior command.

* added to rmware 5/22/13

Proximity and iClass Input, Format # 2 Mask, Part 1*

X056 p1 ll1 p2 ll2

p1 start position 00=ll1 is a constant

ll1 length or constant

p2 start position 00=ll2 is a constant

ll2 length or constant

p1 and p2 refer to the start position in the data to start an extraction of

data. The data is extracted for a length of ll1,ll2. If p1 or p2 is 00, then

ll1 or ll2 refers to a constant value which will be inserted into the data

value. The constant value is a 3-digit ascii decimal value of the character

to insert (“A” = 065). If both p1 and ll1 (or p2 and ll2) are 0, then that

portion of the mask is ignored. See the examples at the end of this

section.

Note this mask applies only to prox/iClass cards with a bit length dened

by prox/iClass format # 2.

* added to rmware 5/22/13

PROGRAMMING

PROX ICLASS
