Qscan User’s Guide Version 1.4

Page 40

Proximity and iClass Input, Format # 3, Part 2*

X053 iss il b sc ic uc

iss issue code start bit max=250

il # bits for issue code 000=no issue

b issue code is lsb 0=off 1=issue is lsb

sc site characters 00=none max=20

ic id characters 00=none max=20

uc issue characters 00=none max=20

This command is the second part of a 2 part command, for setting up an

input proximity or iClass format.

* added to rmware 5/22/13

PROGRAMMING

PROX ICLASS

Proximity and iClass Input, Format # 1 Mask, Part 1*

X054 p1 ll1 p2 ll2

p1 start position 00=ll1 is a constant

ll1 length or constant

p2 start position 00=ll2 is a constant

ll2 length or constant

p1 and p2 refer to the start position in the data to start an extraction of

data. The data is extracted for a length of ll1,ll2. If p1 or p2 is 00, then

ll1 or ll2 refers to a constant value which will be inserted into the data

value. The constant value is a 3-digit ascii decimal value of the character

to insert (“A” = 065). If both p1 and ll1 (or p2 and ll2) are 0, then that

portion of the mask is ignored. See the examples at the end of this

section.

Note this mask applies only to prox/iClass cards with a bit length dened

by prox/iClass format # 1.

* added to rmware 5/22/13
