5.
To reinstall the condensate retainer, tilt
the retainer to enable you to slide the
two tabs under the chassis of the boiler,
and secure with the wing nuts.
6.
The drain hose should run to a suitable
drain or condensate neutralizer.
Figure 31 Condensate trap drainage
Flue gas exhaust: Condensate and rain water flow back from venting system
Warning:Risk of damage to appliance. Ensure rainwater is prevented from entering air
3.9 Installing the condensate trap
