iBeam TE-JPKT - Wiring Diagram; Product Specifications; Camera Technical Details; System and Environmental Specs

4. Wiring diagram
5. Specifications
Sensor
CMOS 7080
Resolution
480 TV Lines
Field of view
Diagonal 170º, Horizontal 110º, Vertical 90º
Illumination
0.6 Lux
IP rating
IP67
Parking Lines
Defeatable (white loop on harness)
Extension cable
26’
TV system
NTSC
Working Temp
-20ºC ~ 70ºC
Warranty
3 years
2 ft
22 ft
