ibis Mojo Sl-R User Manual

31
Rear Shock Set-Up
est performance shocks on the market.
The reduced surface area provides
a very active and supple ride quality
while the smaller air canister gives you
a progressive spring curve. With adjust-
able rebound and lockout adjustment
this shock compliments the Ripley’s own
capabilities well.
X-Fusion O2 RCX
The Special Blend Mojo SL and HD-R
are equipped with X-Fusion’s O2 RCX
rear shock custom tuned for the Mo-
jo’s dw-link suspension design. The O2
RCX features 4 stages of Low-Speed
Compression (LSC) adjustment using
the blue lever and rebound adjustment
using the red dial. The X-Fusion LSC
adjustment will increase the compres-
sion force throughout the entire stroke
of the shock rather than creating a
pedal platform. The 4 stages of LSC
can be described as open, firm, firmer,
firmest when adjusting right to left in a
counter clockwise direction. Using the
4-position LSC adjustment riders can
quickly pick the most efficient setting
for the terrain they are riding.
