Ibiza 9beam-mini - 48 Channel Mode

©Copyright LOTRONIC 2016 9BEAM-MINI Page 7
10
0—15
No effect
16—44
Auto running Effect 0(recommend)
45—74
Auto running Effect 1
75—104
Auto running Effect 2
105—128
Auto running Effect 3
129—157
Sound control Effect 0(Recommend)
158—187
Sound control Effect 1
188—217
Sound control Effect 2
218—255
Sound control Effect 3
11
0----255
Speed/Sound control sensitive
12
0----255
Head 1 Red Dimmer
13
0----255
Head 1 Green Dimmer
14
0----255
Head 1 Blue Dimmer
15
0----255
Head 1 White Dimmer
16
0----255
Head 2 Red Dimmer
17
0----255
Head 2 Green Dimmer
18
0----255
Head 2 Blue Dimmer
19
0----255
Head 2 White Dimmer
20
0----255
Head 3 Red Dimmer
21
0----255
Head 3 Green Dimmer
22
0----255
Head 3 Blue Dimmer
23
0----255
Head 3 White Dimmer
24
0----249
No function
250----255
Reset
48 channel definition table
Channel DMX Value
Function
1 0---255
X motor
route
2
X Endless rotation
0---005
No
006---127
X
Clockwise endless rotate
128---255
X
Counter clockwise endless rotate
3 0---255
Y1 motor route
4 0---255
Y2 motor route
5 0---255
Y3 motor route
6 0---255
X/Y1
-3 motor speed
7 0---255
Total dimmer 0
-------100%
8
Strobe
0---9
No strobe
10---249
Strobe speed from slow to fast
250---255
No
9
LED Macro function
0
No effect
1---7
Gradual change effect
8---140
Auto effect(recommend)
140---255
Sound control effect
