IBM 11000VA LCD 5U Rack Uninterruptible Power Supply 5
Specifications
Table 2 lists the specifications for the 11000VA UPS model.
Table 2. Specifications
Specification IBM 11000VA LCD 5U Rack UPS (208V/230V)
IBM part number 5395-9KX
VA/Watts rating 11000 VA/1000 W
Nominal output voltage (Vac) 208 V/230 V auto sensing at first powerup, user
configurable
Rated power output 11000 VA (normal and high efficiency modes)
5500 VA (double conversion mode)
Output power capacity in watts 10000 W (normal and high efficiency modes)
5000 W (double conversion mode)
Load segments Two
Output connections Eight IEC 320 C19
Circuit breakers Four two-pole output breakers rated at 20 A (two
breakers for each load segment)
Efficiency Normal mode: 93%
High efficiency mode: 96%
Battery mode: 90%
Input
Nominal input voltage 208 V/230 V (auto sensing at first powerup)
Maximum input current 69.96 A (line mode)
58.33 A (battery mode)
Input frequency (auto sensing) 50/60 Hz +/- 3 Hz
Input connection type Hardwired to terminal block
Included line (input) cords None
Input voltage range, mains operations 155-255 V for 208 V
Batteries
Typical run times See Table 3
Battery type Valve Regulated Lead Acid (VRLA): maintenance-free,
sealed, leak-proof
Optional External Battery Pack Yes, 69Y1986
Typical recharge time 3 hours to 90% charge from a UPS/battery discharge of
50% rated load
