IBM 2254 Hardware Maintenance Manual

POST Error Code FRU/Action
Tape Drive green ″in use″ LED fails to come
on
1. Tape Drive
2. SCSI Adapter or System Board
3. SCSI Cable (internal)
4. SCSI Cable (external)
Tape automatically ejected from drive
1. Tape Cassette
Drive
SCSI ID on rotary switch does not match
SCSI ID set in configuration. Verify drive
switches inside cover are set to zero
1. Rotary Switch Circuit Board
2. Circuit Board Cable
3. Tape Drive
Tape sticks or breaks in drive.
Verify that the tapes used meet ANSI
standard X3B5
1. Tape Cassette
212XX
1. SCSI Printer
2. Printer Cable
213XX
1. SCSI Processor
214XX
1. WORM Drive
215XXXC, 215XXXD, 215XXXE, 215XXXU
If an external device, and power-on LED is
off, check external voltages
1. CD-ROM Drive I
2. CD-ROM Drive II
Enhanced CD-ROM Drive II
Any CD-ROM Drive
3. SCSI Cable
4. SCSI Adapter or System Board
216XX
1. Scanner
217XX
If an external device, and power-on LED is
off, check external voltages
1. Rewritable Optical Drive
2. SCSI Adapter or System Board
3. SCSI Cable
218XX
Check for multi CD tray or jukebox
1. Changer
219XX
1. SCSI Communications Device
24201Y0, 24210Y0
Be sure wrap plug is attached
1. ISDN/2 Adapter
2. ISDN/2 Wrap Plug
3. ISDN/2 Communications Cable
273XX
1. 1 Mbps Micro Channel
2. Infrared LAN Adapter
27501, 27503, 27506, 27507
1. ServerGuard Adapter
2. System Board
3. Riser card
27502, 27504, 27510, 27511, 27533, 27534,
27536, 27537
1. ServerGuard Adapter
27509
1. Remove redundant adapters, run Auto
Configuration program, then retest.
Chapter 6. Symptom-to-FRU Index 105
