which it cannot be removed; then fasten the cable ends together with a lock.
1Rope Clip
2Bolt holes
3Nuts
What to do next:
To work with another option, go to the appropriate section.
Replacing the cover and connecting the cables - microtower model
After working with options, you need to install any removed parts, replace the
cover, and reconnect any cables, including power cords and telephone lines. Also,
depending on the option that is installed, you might need to confirm the updated
information in the Configuration/Setup Utility program.
To replace the cover and connect cables to your computer:
1. Ensure that all components have been reassembled correctly and that no tools
or loose screws are left inside your computer.
2. Clear any cables that might impede the replacement of the cover.
56 Hardware Maintenance Manual
