Attaching Output Trays
Follow these steps:
1. Attach tray as shown and insert the two tabs on the tray into the slots on the
2000-sheet finisher. (Tray should snap into place.)
c9pu152
2. Lower the tray until the tray stops.
c9pu153
3. Attach the screws as shown and tighten the screws with your fingers.
c9pu154
4. Repeat for the other two trays.
Chapter 7. Installing Printer Options 185
