LED locations
All the switch LEDs are located on the port side. Figure 8 shows the location of
individual LEDs
Item LED names and descriptions
A System power LED (green)
B System status LED (green/amber)
C Ethernet link status LED
D Ethernet link speed LED
E Port status LED for port 3
F Port status LED for port 7
A
B
CD
E
F
B24_0003
Figure 8. Detailed view, location of LEDs on the switch
22 SAN24B-4 Express Installation, Service, and User Guide
