2x20 Displays
Integrated 2x20 Distributed 2x20
Technology
Vacuum Fluorescent
Format
2 rows, 20 characters
Brightness (w/o
lens)
300 cd/m
2
300 cd/m
2
Display Color (w/o
lens)
Green
Adjustment
None Multi-position detent
Character Box
5 x 7 5 x 7
Character Height
(mm)
7.74 x 4.15 9.5 x 4.45
Emulations
Logic Controls Emulation or IBM Multi-Mode
Character Sets
(IBM Multi-mode)
Code Page 437 (US/Euro)
Code Page 897 (Katakana)
Code Page 858 (Int'l)
Code Page 852 (Central Europe)
Code Page 855 (Cyrillic)
Code Page 857 (Turkey)
Code Page 862 (Israel)
Code Page 863 (Can Fr)
Code Page 864 (Arabic)
Code Page 865 (Nordic)
Code Page 808 (Cyrillic Russian)
Code Page 869 (Greece)
User Defined
Characters
Logic Controls Mode: 1
IBM Mode: 8
Electrical
Interface
TTL Serial RS232
Power
5V 12V
Power
Consumption
(all pixels
energized)
6W 7.2 W
Attachment Cable
Pigtail 3.8 m (12 ft)
SurePOS 500-XX3 supports an integrated and distributed 2x20 customer display. The integrated display
mounts externally to the rear cover and provides a 3 position adjustable viewing range. The distributed
display is a free standing design using existing 4690 style covers using the
SurePOS 500-XX3 color. The
displays are Euro Ready.
SurePOS 500 Model XX3 Technical Reference, v 1.3 Page 29 of
81
