Appendix B Power Specifications
The following chart defines the input requirements and power consumption specifications:
Power Consumption
Off (attached to mains) 7 Watts
Suspend Not supported
Standby 49 Watts
On (idle, no I/O) 60 Watts -?
On (idle, I/O: cd, msr, 2x20, printer) 79 Watts
On (max, printing) 82 Watts
Input Voltage/Frequency
100 ~ 127, 200 ~ 240 V AC (nominal)
50 or 60 Hz (+/- 3 Hz)
Sinusoidal, trapezoidal, or square wave inputs
Maximum kVA
0.21
AC Input Connector/Cable
IEC 320 C14, unshielded right angle type
Leakage current
1.0 ma maximum
Inrush
< 50 A (peak, first cycle)
A. Vibration, Shock, and Drop
1. Operating
Attribute Category/Class Reference Standard
Vibration Class V3 C-S 1-9711-002
Shock Class S3 C-S 1-9711-007
1. Non-Operating
Item
Levels
Reference Standard
Packaged (individual, non-
palletized)
IBM C-H 1-9711-005
Unpackaged
Vibration
Shock (drop table)
50 g's min
C-H 1-9711-001
C-H 1-9711-004
A. Acoustics
1. Classification
Item Category/Class Reference Standard
Acoustics 2B C-S 1-1710-006
SurePOS 500 Model XX3 Technical Reference, v 1.3 Page 34 of
81
