02F8-02FF 8 bytes SMC LPC47M192, Serial Port 2 (Motherboard) SMC LPC47M192

0377, bit 7 1 bit SMC LPC47M192, Floppy Disk Change SMC LPC47M192

0378-037F 8 bytes SMC LPC47M192, Parallel Port (typical, setup

default)

SMC LPC47M192

03F0-03F5 8 bytes SMC LPC47M192, Floppy Controller SMC LPC47M192

03F6 1 byte IDE Channel 0 (decoded by Intel 82801DB

(ICH4))

Intel 82801DB

(ICH4)

03F7,bit 7 1 bit IDE, Floppy Disk Change (Intel 82801DB

(ICH4))

Intel 82801DB

(ICH4)

03F7,bits 6:0 7 bits IDE Status Channel 0 (decoded by Intel

82801DB (ICH4))

Intel 82801DB

(ICH4)

03F8-03FF 8 bytes SMC LPC47M192, Serial Port 1 (Motherboard) SMC LPC47M192

0CF8-0CFB 4 bytes Intel 82845GV/Intel 82801DB (ICH4) PCI

Configuration Address Register

Intel MHC4 and

ICH4

0CFC-0CFF 4 bytes Intel 82845GV/Intel 82801DB (ICH4) PCI

Configuration Data Register

Intel MCH4 and

ICH4

SurePOS 500 Model XX3 Technical Reference, v 1.3 Page 39 of
