The following table shows all the commands:
Function Comman
d Byte
Format
Reset “00” “:0100001100EE”
Set Configuration “01” :0600001101<b1><b2><b3><b4><b5><ss>
ss = - (18h +b1+b2+b3+b4+b5)
Get Configuration “02” :0200001102<source><ss> : source = “00” from RAM or “01” from flash.
From ram: “:020000110200EB”
From flash: “020000110201EA”
Start Update
Mode
“07” “:0100001107E7”
Commit
Configuration
“09”
“:0100001109E5”
Custom
Configuration
Enable/Disable
/x0A “:020000110A<value><ss>
value=”01” enable custom configuration: “:020000110A01E2”
value=”00” disable custom configuration. “:020000110A00E3”
Start Command
Mode
“10” “:0100001110DE”
Start Functional
Mode
“11” “:0100001111DD”
General device responses are:
Function ID byte Format
Status “7F” :nn0000117F<b1><b2><b3><b4><b5><revision string[11]><ss>
Data return
(not used )
“82” :nn00001182<command><data packet><ss>
Command
Response w/ no
data
Success ‘.’
Fail ‘X’
Command specific responses are:
Function
Success Response Fail Response
Reset
“.” “X”
Set Configuration
“.” “X”
SurePOS 500 Model XX3 Technical Reference, v 1.3 Page 73 of
81
